** THIS KIT DOES NOT INCLUDE LOWER RECEIVER OR MAGAZINE **

** ASSEMBLED UPPER & TEST FIRE MAY TAKE UP TO 7-10 BUSINESS DAYS TO PROCESS **

** KITS CANNOT BE CHANGED, NO MODIFICATIONS WILL BE ACCEPTED *

**UNDER CALIFORNIA STATE LAW AB 857: 80% LOWER RECEIVERS WILL NOT BE SHIPPED TO CA RESIDENTS (separate or in kits)**

AR-15/47/9/300AAC Clamp On Rail System

Material: Aircraft grade 6061 aluminum/locking

Length: 7''

Keymod location: 3, 6, 9, 12 o’clock location

Top rail has full complete pica-tinny rail.

Finish: Black annodized

Barrel nut material:  Steel

Clamp on design with proprietary screw to lock on the rail to the barrel nut.

Flush fitment on receiver no gap

Spanner wrench needed to torque barrel nut to spec (not included) and hex wrench

AR-15 7.5" Barrel .223 Wylde 1:7 Twist

• Chamber: 5.56/.223

• Length: 7.5"

• Twist Rate: 1:7

• Gas Port: 0.750"

• Gas System: Pistol

• Thread Pitch: 1/2x28

• Feed Ramps: M4

• Finish: Parkerized

• Made In USA

AR-15 Multi Ported Flash Suppressor Muzzle Brake

• CNC Machined High Quality Steel

• Heat Treated

• Multi Ported Design

• Solid Machined Construction

• Black Oxide Finish

• Tuned ported on top to Reduce muzzle rise

• Solid bottom controls dust printing

• 1/2"x28 Thread Pitch

• Weight: 2.2 oz.

• Lenghth: 2" Approx.

AR-15 Mil-Spec Upper Receiver (Stripped) - Made in U.S.A.

• High quality and lightweight stripped Upper Receiver

• Material: Aircraft grade Aluminum

• Finish: Black Anodized

AR-15 .223/5.56 Bolt Carrier Group- Black Nitride

PROUDLY MADE IN THE USA!

Carrier

• Machined from 8620 tool steel

• Heat treated to military specifications

Bolt

• Machined from 9310 tool steel

• Heat treated to military specifications

• Shot Peened

• Ground to meet military required tolerances

• MPI (Mag Particle Inspected)

Gas Key

• Machined from 4140

• Heat treated to military specifications

Extractor

• Machined from 4140

• Heat treated to military specifications

• Shot peened

Firing Pin

• Machined from 8640 tool steel

• Heat treated to military specifications

• Ground to meet military required tolerances

• Coated with .0002”-.0003” of hard chrome per MIL-STD-171 1.2.2.2

Cam Pin

• Machined from 4340

• Quench and temper heat treat

• Ground to meet military required tolerances

Charging Handle

• Body is 6061 T6 Billet Aluminum

• Latch is 7075 T6

• Black Type III Hardcoat Anodizing


Dust Cover

• Dust Cover, Spring, and Rod are constructed from 4150 Steel

• Black Type III Hardcoat Anodizing


Forward Assist

• Constructed from 4150 Steel

•  Includes Plunger, Forward Assist Pawl, Retainer pin, and spring


Gas Block

• Constructed of Steel

• Set screw mounts

• Fits .750 Dia Barrels

• Color: Black Phosphate finish


Gas Tube

• Material: Stainless Steel (optimal heat and corrosion resistance)

• Mil-Spec Dimensions (consistent gas flow)

• Made in the U.S.A

AR-15 Standard Lower Receiver Parts Kit-LPK17

Complete Kit Includes:

•   Standard AR-15 Pistol Grip (Black)

•     Standard Trigger Guard

•     Semi Trigger

•     Semi Hammer

•     Semi Disconnector

•     Semi Selector

•     Bolt Catch Spring

•     Detent Spring

•     Bolt Catch Buffer

•     Take Down Detent

•     Bolt Catch

•     Magazine Catch Spring

•     Bolt Catch Roll Pin

•     Magazine Catch Button

•     Magazine Catch

•     Front Pivot Pin

•     Hammer Spring

•     Trigger Spring

•     Pistol Grip Screw

•     Pistol Grip Lock Washer

•     Selector Spring

•     Detent Selector

•     Hammer Pin

•     Trigger Pin

•     Take Down Pin

•     Buffer Retainer Pin

•     Buffer Retainer Spring

•     Disconnector Spring

---

AR-15 .223/5.56 Pistol Buffer Tube Kit - No Foam

Includes:

•    Pistol Buffer Tube

•    Buffer

•    Buffer Spring

•    Steel End Plate

•    Steel Castle Nut


Details:

•  CNC machined aluminum buffer tube to fit carbine buffer and spring.

•  Hard anodized type III black finish.

•  Machined lower slot to accept all end plates and sling mounting accessories.

• Superior Quality Carbine Buffer Spring

• Standard 3 oz buffer Quality Polyurethane Bumper for longer life

•   Steel End plate and Castle nut.

•  Buffer tubes measure 7"

---

Foam Pad for AR-15 Pistol Stock Buffer Tube - 5.4"

•     Made of high quality NPVC (Nitrile) and designed to fit over 1.25" diameter Buffer Tubes.

•     Designed with a low profile to clear charging handle action.

•     Length: 5.4375"

•     Width: 1.25" (expandable)

•     Color: Black

New Design Back-Up Front and Rear Sights Combo Sets

Front Sight is adjustable for elevation and fits most 1913 Picatinny-railed hand guards, but is specifically tailored to the AR15/M16 platform.
Features

•     Impact resistant polymer construction

•     Spring-loaded flip up sight easily activated from either side or by pressing the top

•     Detent and spring pressure keeps sight erect but allows for unobstructed folding under impact, etc.

•     Protective wings shield the spring-locking A2 front sight post


Specifications

•     Weight, w/ hardware: 1.2 oz.

•     Height above rail, stowed: ~0.51 in.

•     Length, stowed: 2.6 in.

•     Length, deployed: 1.5 in.

Three Piece Polymer Angled Foregrip Pistol Length

• Three Piece Design

• Includes an interchangeable finger shelf (allows for a flat surface or finger nub)

• All mounting hardware included

• Material: Polymer

• Weight: 1.8 OZ

• Length: 4.5 INCHES

• Height: 2 INCHES
