AR-15 ''STANDARD'' Pistol Kit

** THIS KIT DOES NOT INCLUDE LOWER RECEIVER OR MAGAZINE **

** ASSEMBLED UPPER & TEST FIRE MAY TAKE UP TO 7-10 BUSINESS DAYS TO PROCESS **

** KITS CANNOT BE CHANGED, NO MODIFICATIONS WILL BE ACCEPTED *

**UNDER CALIFORNIA STATE LAW AB 857: 80% LOWER RECEIVERS WILL NOT BE SHIPPED TO CA RESIDENTS (separate or in kits)**

AR-15 Light Weight Keymod Hand Guard

Birdcage Muzzle Brake

SPECS:
Machined steel 1.75" (4.4cm) long, 7/8" (2.2cm) O.D. ½”-28 tpi.
Includes crush washer

AR-15 7.5" Barrel .223 Wylde 1:7 Twist

• Chamber: 5.56/.223

• Length: 7.5"

• Twist Rate: 1:7

• Gas Port: 0.750"

• Gas System: Pistol

• Thread Pitch: 1/2x28

• Feed Ramps: M4

• Finish: Parkerized

• Made In USA

AR-15 Mil-Spec Upper Receiver- Made in U.S.A.

• High quality and lightweight Upper Receiver

• Material: Aircraft grade Aluminum

• Finish: Black Anodized


---

AR-15 .223/5.56 Bolt Carrier Group- Black Nitride

PROUDLY MADE IN THE USA!

Carrier

• Machined from 8620 tool steel

• Heat treated to military specifications

Bolt

• Machined from 9310 tool steel

• Heat treated to military specifications

• Shot Peened

• Ground to meet military required tolerances

• MPI (Mag Particle Inspected)

Gas Key

• Machined from 4140

• Heat treated to military specifications

Extractor

• Machined from 4140

• Heat treated to military specifications

• Shot peened

Firing Pin

• Machined from 8640 tool steel

• Heat treated to military specifications

• Ground to meet military required tolerances

• Coated with .0002”-.0003” of hard chrome per MIL-STD-171 1.2.2.2

Cam Pin

• Machined from 4340

• Quench and temper heat treat

• Ground to meet military required tolerances

Charging Handle

• Body is 6061 T6 Billet Aluminum

• Latch is 7075 T6

• Black Type III Hardcoat Anodizing


---

Dust Cover

• Dust Cover, Spring, and Rod are constructed from 4150 Steel

• Black Type III Hardcoat Anodizing

---

Forward Assist

• Constructed from 4150 Steel

•  Includes Plunger, Forward Assist Pawl, Retainer pin, and spring

---

Gas Block

Specifications:

• Constructed of Steel

• Set screw mounts

• Fits .750 Dia Barrels

• Color: Black Phosphate finish


---

Gas Tube

• Material: Stainless Steel (optimal heat and corrosion resistance)

• Mil-Spec Dimensions (consistent gas flow)

• Made in the U.S.

---

AR-15 Standard Lower Receiver Parts Kit-LPK17

Complete Kit Includes:

•   Standard AR-15 Pistol Grip (Black)

•     Standard Trigger Guard

•     Semi Trigger

•     Semi Hammer

•     Semi Disconnector

•     Semi Selector

•     Bolt Catch Spring

•     Detent Spring

•     Bolt Catch Buffer

•     Take Down Detent

•     Bolt Catch

•     Magazine Catch Spring

•     Bolt Catch Roll Pin

•     Magazine Catch Button

•     Magazine Catch

•     Front Pivot Pin

•     Hammer Spring

•     Trigger Spring

•     Pistol Grip Screw

•     Pistol Grip Lock Washer

•     Selector Spring

•     Detent Selector

•     Hammer Pin

•     Trigger Pin

•     Take Down Pin

•     Buffer Retainer Pin

•     Buffer Retainer Spring
•   Disconnector Spring

AR-15 .223/5.56 Complete PISTOL BUFFER TUBE

Includes:
        Pistol Buffer Tube
        Buffer Tube Foam Pad
        Buffer
        Buffer Spring
        Steel End Plate
        Steel Castle Nut
Detail:
        CNC machined aluminum buffer tube to fit carbine buffer and spring.
        Hard anodized type III black finish.
        Machined lower slot to accept all end plates and sling mounting accessories.
        Superior Quality Carbine Buffer Spring
        Standard 3 oz buffer Quality Polyurethane Bumper for longer life
        Steel Ambidextrous End plate and Castle nut.
        Buffer tubes measure 7-5/16"
        Buffer Tube Foam Pad is made from NPVC also known as NBR or Nitrile.
